70mm Hydra rocket AV02 tests, last prototype with modified T tail


Hellfire AV02 test


Test of deice system


AV02 with final tail in Farnborough 1982 airshow


AV04


PV02 at Yuma Providing Ground, Arizona


PV06 in summer 1984, Yuma, Arizona, Initial Key Personnel Training (IKPT)


First serial Apache series started with PV14 allocated to units


(from left) AV04,AV05,AV06


Prototype YAH-64 with smal vertical stabilisation facets on horizontal stabiliser


AV04 with final tail stabiliser, also with new device suppressing IR mark


Visit in Ryan Aeronautical (most of all structure parts are made here), TADS/PNVS is made from wood, used on AH-64 prototypes
